WD80 Hydraulic Power Pack System


The WD80 Hydraulic Power Pack is specifically designed to operate the Mini Pamper, Twin Brush Machine and the hand tool. It is capable of operating one Mini Pamper on it's own, or two of the smaller machines. Both the 50 metre and 100 metre umbilicals are designed to suit the WD80.



Specifications
  • Dimensions | Length 1850mm, Width 1000m, Height 1260mm
  • Weight | Excluding fluids 640kg Including fluids 820kg
  • Engine | KUBOTA V2203E diesel engine, 4 cylinders in line, on Anti vibration mounts.
    29.8 kW (40.0 HP) @ 2800 rpm (SAE Net Continuos) Water-cooled
  • Output | Combined flow 80 lpm – pressure 2200 psi (152 bar) at 2,500 rpm. Flow can be divided equally for the use of 2 hand tools. Maximum flow set by engine revs, individual branch flow can be adjusted using pressure compensated flow controls to divert part of the flow back to tank
  • Connections | Each circuit is fitted with Holmbury flat face (male supply, female return) ¾”
  • Electrical output | 12v and 24v DC connections are fitted 24v is produced using DC/DC converter, max output 100W for vehicle lights
  • Controls | Electric start, throttle lever, flow-combining valve, flow on/off valve to each hydraulic outlet, flow adjustable (0-25 litres) to each hydraulic outlet. Stop solenoid
  • Alarms | Audible & visual alarms with automatic shut down
  • Indicators | Fuel tank sight glass gauges. Pressure and flow gauges. Hour meters
